Low-pressure die casting

This process provides excellent internal mechanical properties because the filling is very controlled.

The central feeding with the possibility to multiply the pouring attacks are particularly suitable for the production of sand-core and complex parts.

Advantages

1.Very good strength values

2.Complex geometries possible as sand

cores can be used

3.High dimensional accuracy

4.Whole process well-suited to automation

5.Less complicated machine and die technology

Disadvantages

1.Slower casting cycles

2.Minimum wall thickness approx. 3 mm (in die)

How it works

A sealed furnace holding molten metal is placed below a die with the desired mold shape.

Pressurized air, typically between 0.5 to 8 bar （7.25 to 116 psi),is applied to the surface of the molten metal in the furnace.

This pressure forces the molten metal to rise slowly and steadily through a riser tube into the mold cavity from the bottom up.

The pressure is maintained until the casting solidifies, which helps feed the metal to compensate for shrinkage.

Once cooled, the die is opened, and the finished part is removed.

Key benefits and applications

High-quality parts:  The slow, turbulence-free filling process produces parts with excellent density, mechanical properties, and a fine microstructure.

Good surface finish: The process results in good surface smoothness and dimensional accuracy.

Reduced defects: Minimal oxidation occurs because the metal is submerged and protected by a blanket of gas, and the slow filling prevents defects like cold runs.

Applications:  It is commonly used for casting high-performance aluminum parts, such as wheel rims, suspension/chassis parts, and electric motor housings for the automotive and energy industries.

Comparison to other casting methods

vs. Gravity Casting:

Low-pressure casting is more expensive but produces denser parts with better

mechanical properties due to the use of pressure, which also minimizes oxidation.

vs. High-Pressure Die Casting:

Low-pressure casting is slower and less suitable for mass production, but it creates Low-pressure casting is slower and less suitable for mass production, but it creates  uses much higher pressures and is better for producing large quantities of parts.

The material used is A356,T4-T6 heat-treated.

Services and Parts

Specialist support at your side.

With a strong global networt of trained service technicians and strategically located spare parts warehouses,we can service and optimise die casting machines to ensure stable manufacturing and maximum machine uptime.

Automated Die Casting Cells

Automatic work cells that integrate all peripheral devices, from the furnace to automatic deburring.

Low Pressure Die Casiting

Flexible low pressure die casting(LPDC) machines and fully automated cells from italpresse gauss for the efficient production of complex parts

Competitive Advantage

Factory customization:  We design our product to meet specific customer requirements, providing a tailored solution for unique applications. We work closely with clients to ensure that the final product meets their exact specifications.

High-Quality Materials: The product is crafted from high-quality aluminum alloy, providing excellent durability and heat dissipation properties, making it ideal for applications such as LED lamp components.

ISO 9001:2015 Certification:  Our manufacturing process adheres to the strict standards of the ISO 9001:2015 certification, guaranteeing a high level of quality and reliability in our products.

Custom Packaging:  We offer customized packaging options, including carton packaging, to ensure the safe and secure delivery of the product to our clients worldwide.

Competitive Pricing:  We offer competitive pricing with a minimum order quantity of 100 pieces, making our product an attractive option for businesses looking to source high-quality aluminum die-cast parts while minimizing costs.

FAQ

Q1. Are you a factory or a trading company?

We have our factory. Our factory is located at No.38 Longtanshan Road,Daqi Street ,Beilun District，Ningbo City, Zhejiang Province, China 315800

Welcome to visit our factory.

Q2. What production services do you offer?

Mold design and manufacturing, die casting, CNC machining, assembly, and surface treatment.

Q3. What is the lead time?

mold: 4–6 weeks

Mass production: 3–4 weeks

Q4. How about your quality assurance?

♦ We are certified to ISO 9001:2015 and IATF 16949.

♦ After sample approval, we will prepare operation instructions for production.

♦ We conduct 100% product inspection before shipment.

Q5. How long does it take to get a quotation?

We will provide a quotation within 2 days after receiving detailed information (your 2D/3D drawings or samples).

Q6. What factors are included in your quotation?

Drawings or samples, materials, surface treatment, and quantity.

Q7. What are your payment terms?

Mold: 50% deposit in advance, balance due after sample approval.

Goods: 50% deposit in advance, balance via T/T before shipment Or CFR and CIF
